Createn rotary switch

Rotary Switches

SPECIFICATIONS

Contact Rating: 10mA 12V DC
Mechanical Life: 100,000 cycles

Electrical Life: 50,000 make-and-break cycles at full load

Contact Resistance: 3Ω max.
Insulation Resistance: 100MΩ min. 50V DC

Dielectric Strength: 100V AC/1minute

Travel:  0.5±0.3mm

Operating Force: 610±306gf.cm
Operating Temp: -20°C to +85°C



































Rotary Switches

SPECIFICATIONS

Contact Rating: 10mA 5V DC
Mechanical Life: 100,000 cycles

Electrical Life: 50,000 make-and-break cycles at full load

Contact Resistance: 3Ω max.
Insulation Resistance: 100MΩ min. 250V DC

Dielectric Strength: 300V AC/1minute

Operating Force: 50~200gf.cm

Operating Temp: -20°C to +85°C
