Specification
RATING: 30mA / 28VDC
OPERATING SPEED: 10mm/sec
OPERATING FREQUENCY: 25-30 operation cycles per minute.
ELECTRIC LIFE: 20,000 cycles
MACHANICAL LIFE : 500,000 CYCLES
FORCE 1 : 5~7N ; FORCE 2 : 10~13N
OPERATING POSITION 1 : 11.8±0.2mm
OPERATING POSITION 2 : 11.0±0.2mm
FULL TRAVELS: 2.0mm
OPERATING TEMPERATURE: -40°C to 85°C
Materials
PUSHER: POM Natural
DUST PROTECTION CAP: POM
CASE: PA Nature glass fiber reinforced
SPRING: Piano wire
CONTACT: Brass, gold plated
TERMINAL: Brass, gold flash plated
Applications
Industrial control instruments, Control panels, Industrial equipment, Industrial controllers
