1. RoHS compliant
2. Lead free
3. Dual color LED (Blue+Green) is available
Specification
RATING:2A 24VDC
ELECTRICAL LIFE:Min. 10,000 cycles.
MECHANICAL LIFE:1,000,000 cycles.
INSULATION RESISTANCE : 100mΩ min. at 500VDC
OPERATING TEMPERATURE RANGE:-20°C ~ 65°C
TRAVEL:1.5(0.59inch)±0.3mm
INGRESS PROTECTION:IP67 (In house test)
Materials
CASE & BUSHING:Nylon 6/6
CAP:Polyurethane
BUTTON:Stainless steel
ACTUATOR:POM
Applications
industrial control,lighting device, computer peripherals, communication equipment, medical equipment, marine equipment and crane equipment
